PHOTO LIBRARY

From Article

Tips on Electrical System Use and Maintenance

Part IV: Adding New Equipment

Photos by David H. Pascoe, Marine Surveyor

RotarySwitches.JPG (59863 bytes) As versatile as it can get. This boat has (2) 125 and (1) 250 shorelines plus generator for a total of 4 power sources. These are controlled by the six rotary switches, each with four positions,  so that any combination of power sources on any branch circuit can be selected.

Go to Article

Part

Yacht Survey Photos:
Tips on Electrical System Use and Maintenance

I Introduction 2 photos
II High Voltage (AC) Systems 0 photos
III DC Systems 6 photos
IV Adding New Equipment one photo



First posted July 14, 1998 at www.yachtsurvey.com.

Posted  November 17, 1998
